ABB ACS880-01-156A-5 | Industrial Drive – 156 A, 500 VAC

Description Product Introduction The ABB ACS880-01-156A-5 is a high-power industrial drive from ABB’s ACS880 series—the platform designed for demanding applications like large pumps, compressors, fans, extruders, mixers, and material handling systems. This drive delivers 156 A continuous output at 500 VAC, making it suitable for 100 HP (75 kW) motors. The “-01” suffix indicates a wall-mounted enclosure (IP21), and the “-5” indicates 500 VAC input rating. What makes the ABB ACS880-01-156A-5 the go-to drive for large industrial installations is the combination of power density and control capability. ABB’s Direct Torque Control (DTC) delivers torque response in under 1 ms—critical for applications requiring precise speed and torque regulation. The drive includes a coated circuit board standard, a built-in assistant control panel, and a modular I/O design. In my experience, the ACS880-01-156A-5 is the sweet spot for large single-motor applications. It’s a standalone wall-mounted unit—no cabinet required—which saves panel space and installation cost. The “156A” version is common for 100 HP motors in water treatment, mining, and manufacturing. Key Technical Specifications Parameter Specification Model ABB ACS880-01-156A-5 Series ACS880 (Industrial) Input Voltage 380–500 VAC ±10%, 3-phase, 50/60 Hz Output Current 156 A (continuous) Motor Power 100 HP (75 kW) at 500 VAC; 75 HP (55 kW) at 380 VAC Overload Capacity 150% for 60 seconds (heavy duty), 110% for 60 seconds (light duty) Control Method Direct Torque Control (DTC), scalar V/Hz Torque Response < 1 ms Enclosure IP21 (NEMA 1) – wall-mounted Control Panel Assistant control panel (standard) Communication Modbus RTU (RS-485) built-in; optional fieldbus adapters (PROFINET, EtherNet/IP, PROFIBUS, DeviceNet, CANopen) I/O 6 digital inputs, 3 digital outputs, 2 analog inputs, 1 analog output, 1 relay output (expandable) Safety Safe torque off (STO) integrated (SIL 3) Ambient Temp -15°C to 50°C (derate above 40°C) Dimensions Approximately 30″ H x 14″ W x 12″ D Weight Approx. 110 lbs (50 kg) Compliance UL, cUL, CE, RoHS, EAC, TÜV (functional safety) Firmware / Software Versions & Upgrade Notes The ABB ACS880-01-156A-5 contains firmware that is field-upgradable using Drive Composer Pro software and a PC connection. Minimum firmware: Version 3.0 (shipped on units manufactured after 2018). Version 2.x units exist—check the label. Recommended firmware: Version 3.2 or later. Version 3.2 adds enhanced encoder interface support and improves the energy optimizer for pump applications. Software compatibility: Drive Composer Pro 2.5 or later. The free Drive Composer Starter can view parameters but cannot upgrade firmware. Upgrade procedure: Connect a PC to the drive’s control panel port (USB via the control panel or RS-485 adapter). Use Drive Composer Pro to load the firmware file. Takes about 10 minutes. Do not interrupt power during upgrade. Rollback: Supported but requires a full parameter backup first. The drive resets to factory defaults after firmware downgrade. ⚠️ Field note: The ABB ACS880-01-156A-5 is heavy—110 lbs. Use a lifting aid during installation. The wall-mount brackets are designed for concrete walls or heavy-gauge steel. Do not mount on drywall or lightweight framing. I’ve seen installations where undersized anchors pulled out under the drive’s weight. Compatibility & Replacement Matrix Original Model Replacement Model Compatibility Level Key Notes ABB ACS800-01-156A-5 ABB ACS880-01-156A-5 Drop-in (with parameter conversion) Same mounting holes, similar wiring terminals. Parameters transfer via Drive Composer. DTC is standard on ACS880. ABB ACS880-01-156A-5 (same) ABB ACS880-01-156A-5 Drop-in Direct replacement. Any ACS880-01-156A-5 revision is interchangeable. ABB ACS880-01-187A-5 (higher current) ABB ACS880-01-156A-5 Not recommended 187A is for 125 HP. Downgrading may cause overload trips if motor exceeds 156 A. ABB ACS880-01-130A-5 (lower current) ABB ACS880-01-156A-5 Not recommended Undersized for 100 HP motor. Only use if motor is actually smaller. Third-party VFD (100 HP) ABB ACS880-01-156A-5 Needs adaptation Different wiring, programming, and communication mapping. Not a plug-and-play swap. Frequently Asked Questions Q: What motors can I run with this drive? The ABB ACS880-01-156A-5 can run standard induction motors (squirrel cage), permanent magnet motors, and synchronous reluctance motors. It’s rated for 100 HP at 500 VAC, 75 HP at 380 VAC. The drive uses Direct Torque Control (DTC), which delivers full torque at zero speed without an encoder. Q: What are the physical dimensions and clearance requirements? The ABB ACS880-01-156A-5 measures approximately 30″ H x 14″ W x 12″ D. ABB requires 8″ clearance above and below for cooling airflow. Side clearance is 4″ minimum. The drive weighs about 110 lbs—use a lifting bar or mechanical lift for installation. Q: Does this drive include a brake chopper? No. The ABB ACS880-01-156A-5 does not have a built-in brake chopper. For applications requiring dynamic braking (cranes, hoists, centrifuges), you need an external brake chopper (ABB JBR series) sized for 156 A. The drive has terminals for connecting an external chopper and includes a built-in brake control algorithm. Q: How do I set up the safe torque off (STO) function? The ABB ACS880-01-156A-5 has STO terminals (X1:2 and X1:3). To enable the drive, you must close a 24 VDC loop across these terminals. For safety applications, connect them to a safety relay. The STO function is SIL 3 certified—it removes power from the IGBT gate drivers, preventing the motor from generating torque. This drive also supports optional safety functions like Safe Stop 1 (SS1) with an additional safety module. Q: What fieldbus options are available? The ABB ACS880-01-156A-5 has a built-in Modbus RTU port (RS-485). For other protocols, add an option module: FENA-11: EtherNet/IP, Modbus TCP, PROFINET IO FENA-21: EtherNet/IP with dual ports (ring topology) FPBA-01: PROFIBUS DP FCAN-01: CANopen FDEV-01: DeviceNet The option module plugs into the drive’s option slot (slot 2). Configuration is done via parameters 50–53. Q: How do I wire the main power? The ABB ACS880-01-156A-5 requires 380–500 VAC, 3-phase input. Use copper conductors sized per NEC or local code for 156 A continuous. The drive has integrated input fuses (or you must install external fuses per the manual). Input and output terminals are rated for 1/0 AWG to 4/0 AWG depending on terminal type. Torque specifications are printed on the terminal covers. Q: My drive trips on “DC OVERVOLTAGE.” What causes this? DC overvoltage on the ABB ACS880-01-156A-5 means the DC bus voltage exceeded the trip limit. Common causes: Overhauling load (motor is driving the load, not the drive) Input voltage spikes No brake chopper installed for regenerative applications For overhauling loads, add a brake chopper and resistor. For input voltage issues, check the supply line for surges. Q: What’s the warranty on this drive? New ABB ACS880-01-156A-5 drives carry a 24-month warranty from the date of manufacture (ABB standard) or 18 months from shipment, whichever is earlier. Many suppliers offer an additional 12-month warranty. Check with your specific supplier for terms. Q: How do I tune the drive for a 100 HP motor? Run the motor ID run (autotune). With the motor disconnected from the load, set parameter 99.13 to “Standard” and set parameter 99.14 to “ID Run.” The ABB ACS880-01-156A-5 will energize the motor, rotate it (if selected), and calculate all motor parameters automatically. The ID run takes 3–7 minutes depending on motor size. 3BSE031155R1 3BSE018103R1 FCS 1756-IB32K AO895 DCS DSQC679 ABBNO3HAC028357-001PLC 6AV36883ED130AX0 DCS Email: [email protected] Phone: 86 15340683922 Sales:Wu Jiedong Our products are guaranteed for 1 year, with new and original production stopped and imported spare parts. All prices listed on the official website are subject to confirmation by contact: Wu Jiedong (manager). Our product: brand new original packaging Our warranty: All new or repaired parts have a 12 month warranty period beginning Our payment: 100% telegraphic transfer of inventory items before shipment, conditions can be proposed! If you have any downtime spare parts that you cannot find, please feel free to call or use email to contact me. If there are issues that the product cannot solve, please contact me. Product prices can be negotiated. Please do not consider contacting me!
